fig. 38.1
Stop light (fig. 38.1)
To expose the number plate bulb, withdraw the lamp
holder from the number plate holder, then extract the
bulb and replace it.
To replace the stop and parking light bulb, lift the tail
guard and unscrew the two screws (1) that secure the
glass (2). The bulb is of the bayonet-type: press and
rotate anti-clockwise to remove; fit the spare bulb by
pressing and turning clockwise until it clicks.
Refit the glass (2).
Number plate light (fig. 38.2)
To expose the number plate bulb, take the lamp holder
out of the number plate mount, extract the bulb and
replace it.
fig. 38.2
