Legend of fuse box (4)
Pos. Description Rat.
1-9 Main switch 30 A
2-10 Fuel pump, injectors, coils 20 A
3-11 Key sense 7.5 A
4-12 CPU power supply 3 A
5-13 High beam and low beam 15 A
6-14 Turn indicators, warning lights, 10 A
tail lights and instrument panel
lights
7-15 Stop, warning horn 7.5 A
8-16 Cooling electric fan 7.5 A
Note
The electric system wiring diagram is at the end of
this manual.
Wire color coding
W-Y White-Yellow
P Pink
Y-G Yellow-Green
G Green
R-G Red-Green
W-R White-Red
W White
V-Bk Violet-Black
Y Yellow
W-G White-Green
Bn Brown
G-W Green-White
W-Bk White-Black
R-Bk Red-Black
R-B Red-Blue
Gr-R Grey-Red
R Red
W-Bn White-Brown
O Orange
Bn-W Brown-White
Y-Bk Yellow-Black
Gr Grey
B-Bk Blue-Black
Lb Light blue
Bk Black
V-W Violet-White
Y-B Yellow-Blue
Bn-G Brown-Green
G-Gr Green-Grey
O-G Orange-Green
