Ducati SCRAMBLER 2023 User Manual

Lubrication

Have drive chain cleaned by a Ducati Dealer or
authorised Service Centre.

Use SHELL Advance Chain to lubricate the
chain; the use of non-specific lubricants could
damage the O-rings and therefore the entire drive
system.
It is recommendable to lubricate (5) the chain
without waiting for it to cool down  using the
motorcycle, so that the new lubricant can penetrate
 between the inner and outer links and be
more  in its protective action.
Place the bike on the rear paddock stand. Make the
rear wheel turns fast in the opposite direction to the
direction of travel.
Fig 185
276

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
