Unpacking
Inspect your ConvertibleTM amp for hidden damage that may have occurred in transit.
Your amp was inspected and sound tested before shipment from the factory.
All claims for shipping damage must be made by the receiver. Save your box and
packing material for evidence of damage if it has occurred.
Packing Materials
The original box and packing materials are specially designed to protect your amp during
shipment. SAVE ALL PACKING MATERIALS. In the unlikely event that your amp
needs to be returned to the factory, the original box and packing material will be
necessary for shipment. These are carrier approved packing materials and they will
insure safe transit back to the factory.
Specifications for 100 watt Convertible Amps
Combo Head
Weight:
57 lbs 42 lbs
Cabinet Dimensions:
19 3/4" h 10 15/16" h
18 25/32" w 21 25/32" w
11 3/8" d 11 1/16" d
Power Requirements:
120 volts a.c. (U.S. models)
Power Consumption:
480 watts at full rated output.
Power Circuit:
All tube, EL-34 tubes 100 watt rms
@ 8 ohms from 8 ohm output @
120 v.a.c. @ 5% @ 1 khz.
Damping Factor:
From damping output: - Low 0.1
into 4 ohms', - High 4.0 into 8
ohms
Input Impedance:
4.7 meg-ohms adjustable to zero
via load resistor plugs.
Input Sensitivity:
(With Normal, Normal,
Normal modules): 1.2 millivolts.
Dynamic Headroom:
4-5 db
