M109 6 BAND GRAPHIC EQ
DESCRIPTION
•Upto

±18dBofcutting
orboostingatsixdifferent
frequencies
•Easytoseeandadjustonstage
withglow-in-the-darkgraphics
andilluminatedsliders
CONTROLS

 SLIDERSboostorattenuate
upto±18dBatsixdifferent
frequencycenters

 FOOTSWITCHtoggleseffect
on/bypass(illuminatedred
sliderLEDsindicateon)
DIRECTIONS
•Runacablefromyourguitarto
theSixBandEQ’sINPUTjack
andrunanothercablefromthe
SixBandEQ’sOUTPUTjackto
youramplier.
•Setallsliderstotheir0dB
positionanddepressthe
footswitchtoturnthepedalon.
•ExperimentwiththeSixBand
EQ’stone-shapingcapabilities
bymovingtheslidersupand
downtoboostandcutvarious
frequenciestohearhowthis
affectsthesoundofyoursignal.
SPECIFICATIONS
InputImpedance 470kΩ
OutputImpedance 5kΩ
MaxInputLevel 0dBV
MaxOutputLevel 0dBV
NoiseFloor* -95dBV
Bypass Hardwire
CurrentDraw 3mA
PowerSupply 9voltsDC
*A-weighted
DUNLOP MANUFACTURING, INC.
P.O. BOX 846 BENICIA, CA 94510 U.S.A.
TEL: 1-707-745-2722 FAX: 1-707-745-2658
POWER
TheMXRSixBandEQispowered
byone9-voltbattery(remove
bottomplatetoinstall),a9-volt
ACadaptersuchastheDunlop
ECB003/ECB003E,oraDCBrick
™

powersupply.
