DUOTONE CLICK BAR MANUAL
FEATURES
4.3.1.1. REASSEMBLING THE IRON HEART
AFTER RELEASE, KEEP THE RED SAFETY LINE PULLED IN DURING ASSEMBLY AND KEEP AN EYE
ON YOUR KITE AT ALL TIMES. MAKE SURE NOT TO GET CAUGHT IN DRIFTING LINES. NEVER WRAP
ANY LINES AROUND YOUR WRIST OR OTHER PARTS OF YOUR BODY.
1. Hold the release grip pulled upwards and make sure that the Release Pin is open.
2. Put the chicken loop ring on the small metal plate below the Release Pin.
3. Close the Release Pin with one finger while you are still pushing the release handle up.
4. Let the release handle slide down to lock the Release Pin in place.
Pictures
11
+
12
+
13
+
14
page 22
4.3.1.2. HOOKING INTO THE HARNESS
4.3.1.2.1. FREERIDE, FREESTYLE AND WAKESTYLE CHICKEN LOOP CONNECTION TO
THE HARNESS
1. Hook the closed chicken loop into the kite’s harness hook.
2. Turn the chicken stick to the right position.
3. Secure the chicken loop in the harness hook using the chicken stick.
Pictures
15
+
16
page 23
4.4.2.2. ROPE HARNESS LOOP CONNECTION TO THE HARNESS
1. Open the chicken loop.
2. Thread the loop around the designated rope at the harness.
3. Now reassemble the Iron Heart as described in section -> 4.3.1.1. REASSEMBLING THE IRON
HEART.
Pictures
17
page 23
