DUOTONE CLICK BAR - Features; Trim Unit

10
DUOTONE CLICK BAR MANUAL
3.1.1. CLICK BAR QUAD CONTROL 12 m - 24 m
IF YOU FLY THE CLICK BAR WITH 12M, REMOVE THE V DISTRIBUTOR II AND FLY WITH OPEN V.
3
page 19
4. FEATURES
4.1. TRIM UNIT
TO POWER OR DEPOWER THE KITE, THE BACKLINES HAVE TO BE UNDER TENSION. THIS HAPPENS
AUTOMATICALLY WHEN THE KITE IS FLYING. IF YOU WANT TO PRE-TRIM THE KITE WITHOUT
TENSION ON THE BACKLINES, PULL THE LEADING LINES WITH ONE HAND WHILST TRIGGERING
THE TRIM UNIT.
4.1.1. DEPOWER
1. To depower your kite, press the Push Button on the Trim Unit.
4
page 20
Each press of the Push Button on the Trim Unit will depower the kite by one level at a time. With 8
levels of power available, the Power Display and the marks on the leading lines will show you which
level you are on at any time.
5
page 20
A
Pigtails
E
Red g 4 Line 20 m, 22 m & 24 m
(For all models regardless of the year)
H
Back Lines
B
Extensions Lines
I
Iron Heart
C
Left Front Line
(red & blue Safety Line)
F
Lower Front Lines
J
Chicken Loop
K
Chicken Stick
D
Upper Front Lines
V-Distributor II
2
page 71
G
SYSTEM / FEATURES
