28
EN
CONTROL PANEL DISPLAYS
All settings and search results are clearly displayed
on the LCD screen.
1 Mode display: Displays the selected mode of operation of the 5 modes.
Select different modes by pressing the [+] or [-] key.
2 Target metal indicator: At the top of the screen, the three types of metal
are displayed, depending on which metal you are looking for.
3 Upper scale: Consists of 12 arrows that allow you to identify and
distinguish the target object as accurately as possible. In ALL METAL
mode, all 12 indicators will light up. When selecting the modes, the
eliminated metals will not light up. In pinpoint mode, the upper scale
shows the signal strength.
4 Lower scale: Consists of 12 illuminated segments, which can be used to
determine the position and direction even better.
Mode display
Pinpoint display
Backlight indicator
Target metal indicator
3 Upper scale
(arrows)
Lower scale
(segments)
Target depth display
Battery indicator
Sensitivity
indicator
