2.6 Bobbin case holder
Caution: Danger of injury !
Switch off main switch.
Check and correct bobbin case holder only when the sewing machine
is switched off.
Standard checking
Between the bobbin case 2 and the lug 3 of the bobbin case holder
there must be sufficient clearance so that the needle thread can be
pulled through without hindrance.
Correction
–
Loosen screws 1.
–
Align bobbin case holder (distance 0,6 mm see sketch).
–
Tighten screws 1.
22
1
32
