Machine description
16 Operating Instructions 669 - 00.0 - 08/2019
Fig. 2: Components of the machine (2), with stand MG 56-3
(1) - Operating panel
(2) - Stitch regulator
(3) - Knee switch
(4) - Pedal
(5) - Compressed air maintenance
unit
(6) - Stand MG 56-3
(7) - Control
(8) - Stitch length adjusting wheels
(9) - Reel stand
(10)- Winder
