3.3 Setting the working height
The working height can be set between 79 cm and 110 c m
(measured up to the upper edge of the table top).
The sewing unit is set to the lowest working height of 79 cm by the
manufacturer.
ATTENTION: Danger of breakage !
When loosening the securing screws.
The sewing unit may overturn when the tubular feet of the frame are
pulled out.
Set the height of the sewing unit by pulling equally the tubular feet of
the frame.
–
Loosen the nut 1 (4x) and the s houlder bolts 2 (4x) (clamping of the
front tubular foot).
–
Loosen screws 3 (4x) (clamping of the rear tubular foot).
–
Set the table top to the desired height to be flush.
–
To avoid a tilting, pull out / push in the tubular feet uniformly on
both side.
–
Tighten the shoulder bolts 2 and the screws 3.
–
If you want to set the foot pedal afterwards, please do not tighten
the nut 1 yet. Otherwise it can also be tightened.
6
12
3
