Dutailier E8040C5 - Page 3

COUCHETTE E8140C5
E8140C5 CRIB
COUCHETTE
CRIB
CLÉ ALLEN 5/32" (4mm)
ALLEN KEY 5/32" (4mm)
25
1x
36x
8x
3
20x
(#601002)
8x
CLÉ ALLEN 1/8" (3mm)
ALLEN KEY 1/8" (3mm)
27
1x
(#603616)
I
NSTRUCTIONS D’ASSEMBLAGE
A
SSEMBLY INSTRUCTIONS
299 Chaput
St-Pie (Québec)
Canada
J0H 1W0
450 772-2403, Fax 450 772-5055
info@dutailier.com
MODÈLE : E8140C5
MODEL :
KEEP THESE INSTRUCTIONS AND EXTRA HARDWARE FOR FUTURE USE
GARDER CES INSTRUCTIONS AINSI QUE LA QUINCAILLERIE SUPPLÉMENTAIRE
POUR UTILISATION FUTURE
REV:03 Fev 2017
133249
QUINCAILLERIE / LISTE DES PIÈCES
HARDWARE / PARTS LIST
Page /
Brevet U.S. No.9.138.068
U.S. Patent No.9.138.068
7
VIS 1 3/16'' (30 mm) LONG
SCREW 1 3/16'' (30 mm) LONG
10
RONDELLE D'ARRÊT
LOCK WASHER
8
VIS 1 9/16'' (40 mm) LONG
SCREW 1 9/16'' (40 mm) LONG
9
VIS 2'' (50 mm) LONG
SCREW 2'' (50 mm) LONG
(#603286)
(#603285)
(#603287)
(#603162)
*( Petit lit / Toddler ) *IMPORTANT*
11
VIS 1/2'' (12 mm) LONG
SCREW 1/2'' (12 mm) LONG
6x
(#603298)
