Dutailier E8140C5 - Page 2

I
NSTRUCTIONS D’ASSEMBLAGE
A
SSEMBLY INSTRUCTIONS
299 Chaput
St-Pie (Québec)
Canada
J0H 1W0
450 772-2403, Fax 450 772-5055
info@dutailier.com
MODÈLE :
MODEL :
KEEP THESE INSTRUCTIONS AND EXTRA HARDWARE FOR FUTURE USE
GARDER CES INSTRUCTIONS AINSI QUE LA QUINCAILLERIE SUPPLÉMENTAIRE
POUR UTILISATION FUTURE
REV:03 Fev 2017
133249
QUINCAILLERIE / LISTE DES PIÈCES
HARDWARE / PARTS LIST
Page /
Brevet U.S. No.9.138.068
U.S. Patent No.9.138.068
CLÉ ALLEN 5/32" (4mm)
ALLEN KEY 5/32" (4mm)
25
7
VIS 1 3/16'' (30 mm) LONG
SCREW 1 3/16'' (30 mm) LONG
12x
1x
10
RONDELLE D'ARRÊT
LOCK WASHER
28x
COUCHETTE
CRIB
8
VIS 1 9/16'' (40 mm) LONG
SCREW 1 9/16'' (40 mm) LONG
8x
COUCHETTE
CRIB
9
VIS 2'' (50 mm) LONG
SCREW 2'' (50 mm) LONG
8x
2
E8040C5
E8240C5 E8340C5
E8440C5 E8450C5
E8000K5
*( Petit lit / Toddler ) *IMPORTANT*
(#603286)
(#603285)
(#603287)
(#603162)
(#601002)
CLÉ ALLEN 1/8" (3mm)
ALLEN KEY 1/8" (3mm)
27
1x
(#603616)
11
VIS 1/2'' (12 mm) LONG
SCREW 1/2'' (12 mm) LONG
6x
(#603298)
