115
the PIP channel. In case of 4 or 9 channel screen, it changes the screen to a next one in the sequence.
- FREEZ: freeze a current image.
- SETUP: pop up Setup window.
- PLAY/PAUSE: play/pause recorded data in play mode.
- SEARCH: pop up Search window, or switches play mode to search mode.
- ZOOM: zoom in a current image.
- JOYSTICK (REW): rewind in sequence of 2X, 4X, 8X, 16X, 32X, 62X, Extreme in play mode.
- JOYSTICK (FF): fast forward in sequence of 2X, 4X, 8X, 16X, 32X, 62X, Extreme in play mode.
- JOYSTICK(SETUP): operate with direction keys if Setup window is popped up. (up/down/left/right).
- ENT: view a channel in full screen (by selecting a number with ENTER button).
13.4.3 PTZ Control Mode
Push once to exit DVR mode and turn PTZ mode.
Press number keys + “ENT”(Hold for a while until double beep sounds) key to change to Camera ID that wish to control. If
there is a corresponding Camera ID, a full camera image will show up and PTZ control is possible.
It is able to control 255 devices.
PSET:
- Preset save : Number keys + PSET (Hold for a while until double beep sounds).
- Preset shift : Number keys + PSET
TELE: Zoom Out
WIDE: Zoom In
(NOTE)
When a Key does not Work after Set up
-
If the communication speed of DVR and CP are not co-related, it may not work. Please make sure the Baud rate of Keyboard sets on
9.6kbps.
- Press the button to enter PTZ mode and switch to DVR mode again.
-
Please reboot the DVR.
When Tx Blinks Continually on the LED Window
-
If Tx blinks continually without any operation, it may be mistakenly set up for Joystick.
-
OFFSET of the Joystick may not appropriately set up.
-
Please touch the Joystick and position it on the center.
