Ordering Guide
Dyna-Flo DFC / DFO Series Actuators | Model Numbering System
Sample Part Number
DFC - 2 069 - B H N - X
Denotes Special Construction
X Special (Consult Dyna-Flo Sales Office)
Options
N None (Standard)
Bench Range, psig
FAIL CLOSED FAIL OPEN
A 3 - 15 H 6 - 30 A 3 - 15 H 6 - 30
B 4 - 15 Y 8 - 30 B 3 - 14 I 6 - 28
C 5 - 15 I 9 - 30 C 3 - 13 J 6 - 27
D 6 - 15 J 10 - 30 D 3 - 12 K 6 - 26
E 7 - 15 K 12 - 30 E 3 - 11 L 6 - 24
F 8 - 15 L 14 - 30 F 3 - 10 M 6 - 22
U 9 - 15 M 15 - 30 G 3 - 8 N 6 - 21
G 10 - 15 N 16 - 30 O 6 - 20
V 11 - 15 O 17 - 30 X Special P 6 - 19
P 18 - 30 Q 6 - 18
X Special Q 19 - 30 R 6 - 17
R 20 - 30 S 6 - 16
S 21 - 30 T 6 - 15
T
22 - 30
Travel, Inch
A 3/4 D 2 G 3-1/2
B 1-1/8 E 2-1/2
C
1-1/2 F 3
X Special Tr
a
vel
Actuator Size, in
2
156 156
069 69
220 220
105 105
Valve Mounting Connection, Inch
1 2-1/8
2 2-13/16
3 3-9/16
Action
C Fail Closed O Fail Open
X
N
H
B
069
2
C
W
14 - 26
S Side Mounted Handwheel
T Top Mounted Handwheel
1 Type 1 Up Stop - DFO
2 Type 2 Down Stop - DFO
3 Type 3 Down Stop - DFC
4 Type 4 Up Stop - DFC
5 Type 5 Up Stop - DFC
