3 Tests and Diagnostics
3-6
[CONFIDENTIAL] dynabook PORTEGE A30-E/TECRA A30-G,-J/dynabook S Series Maintenance Manual (960-931)
3.3 Entry of the DMI information
To execute the DMI Entry Utility, select 1 from the test program menu (Top Menu), press
Enter.
NOTE: Before replacing the system board, make a note of DMI information of the
current PCB. The information can be confirmed by the “System Information”
screen displayed after start of test program or with “DMI Entry utility”.
After replacing the system board, execute “DMI Entry utility” to register the
DMI information to the new system board.
The following message will appear. Press Y.
**** Warning : Update DMI really? (y/n) ***
The PC will restart. Press F12 and select the USB memory as the boot device. Then the
following screen will appear.
