Maximum Power Output
(2400 - 2483.5 MHz) IEEE802.11 b/
g/n mode / Bluetooth
Maximum 100mW (20dBm) EIRP
(2400 - 2483.5 MHz) BLE Maximum 10mW (10dBm) EIRP
(5150 - 5725 MHz) IEEE802.11 a/n/
ac mode
Maximum 200mW (23dBm) EIRP
The low band 5.15 - 5.35 GHz is for
indoor use only.
(5745 - 5875 MHz) IEEE802.11 a/n/
ac mode
Maximum 25mW (13.98dBm) EIRP
Europe: Model EM7455
Software (Firmware) Version: SWI9X30C_02.xx
Band Frequencies Conducted Tx
(Transmit) power
tolerances
LTE frequency band support
Band 1 2100 MHz Tx: 1,920–1,980 MHz +23 dBm ± 1 dB
Rx: 2,110–2,170 MHz
Band 3 1800 MHz Tx: 1,710–1,785 MHz +23 dBm ± 1 dB
Rx: 1,805–1,880 MHz
Band 7 2600 MHz Tx: 2,500–2,570 MHz +22 dBm ± 1 dB
Rx: 2,620–2,690 MHz
Band 8 900 MHz Tx: 880–915 MHz +23 dBm ± 1 dB
Rx: 925–960 MHz
Band 20 800 MHz Tx: 832–862 MHz +23 dBm ± 1 dB
Rx: 791–821 MHz
WCDMA frequency band support
Band 1 WCDMA 2100 Tx: 1,920–1,980 MHz +23 dBm ± 1 dB
Rx: 2,110–2,170 MHz
Band 3 WCDMA 1800 Tx: 1,710–1,785 MHz +23 dBm ± 1 dB
Rx: 1,805–1,880 MHz
Band 8 WCDMA 900 Tx: 880–915 MHz +23 dBm ± 1 dB
Rx: 925–960 MHz
User's Manual 7-10
