Corus Evolution
4
C 12.2
The C 12.2 is a compact, trapezoidal 12” / two-way
full-range cabinet offering very high power handling
(500W continuous / 2000W peak) and sensitivity of 97
dB 1W / 1m.
The low frequencies are reproduced by an SMX 2120
woofer, whilst in the high frequency range, a DH3
compression driver in a 90° x 50° constant directivity
horn handles everything above 1650 Hz. Flying points
for eyebolts allow the cabinets to be fl own vertically or
horizontally. Available as an option is the DC-MBC12-
UMH mounting bracket, which is compatible with the
DYNACORD PI-Easy mounting system and supports up
to three levels of orientation. To extend the low bass
performance, a Sub 1.15 subwoofer connected in parallel
is recommended. This combination is also idaeal for an
active two-way system together with the DSP 260 or
DSP 600 controllers and power amplifi ers from the SL
series.
C 15.2
In the C 15.2, DYNACORD is offering an extremely
compact, trapezoidal 15” / two-way full-range cabinet
boasting very good power handling (500W continuous /
2000W peak) and sensitity of 100 dB 1W / 1m for
applications requiring an extended low end.
Here, an SMX 2151 woofer is used, whilst in the high
frequency range, a DH3 compression driver in a 90° x
50° constant directivity horn reproduced everything
above 1550 Hz. Flying points for eyebolts are provided
to permit either vertical or horizontal suspension. Also
available as an option is the DC-MBC15-UMH mounting
bracket, which is compatible with the DYNACORD PI-
Easy mounting system and supports up to three levels
of orientation. To extend the low bass performance, a
Sub 1.18 subwoofer connected in parallel is recommended.
This combination is also ideal for an active two-way sys-
tem together with the DSP 260 or DSP 600 controllers
and power amplifi ers from the SL series.
