22 RUNNINGPAD - USER MANUAL / MANUEL DE L'UTILISATEUR
No. Part No. Description QTY
100 02ALS017 Inner Hexagon Cylinder Screw - M5*12 16
101 01CFF006 Hinge Assembly 2
102 01AFF016 Fixation Board 2
103 03RFF031 Graphite Nylon Sheet - 100*25*0.2 2
104 01RFF001 Middle Aluminium Frame - 726*586*55 1
105 01RFF002 Rear Aluminium Frame - 590*586*55 1
106 03AFF026 Rubber Washer - 40*40*1.3 22
107 03AFF029 Graphite Nylon Sheet - 25*10*0.2 2
108 03RFF030 Magnet Mat 2
109 01RFD007
Magnet with Hole - Ø25*6
2
110 01RFF012
Rear Idler Roller - Ø42*Ø15*510
1
111 02ALM001 Hex Nut 2
112 02RLS014 Inner Hexagon Cylinder Screw - M6*70 2
113 03RFF032 Rubber Washer - 10*30*2.5 2
114 02ALS018 Hexagon Socket Countersunk Head Anti-Drop Screw - M6*25 22
115 07ALB002 PC Pads 8
116 03RFF002 Rear Running Board - 485*513*12 1
117 03RFF008R Right Rear Side Strip - 613*104*28 1
118 07RWN012R Label Back Right Strip - 77.6*590.4*0.5 1
119 03RFF007R Right Front Side Strip - 629*80*14 1
120 07RLB001R Label Front Right Strip - 57.5*624.3*0.5 1
121 03RFF003 Running Belt 1
122 03RFF004 Soft Running Board - 458*1170 1
123 04RFT003 R1 Filter 1
123-120 04RFT001 R1 Filter 1
138No. Part No. Description QTY
124 04RLM014 R1 Guide Line 10 1
125 04RLM015 R1 Guide Line 11 1
126 04RLM016 R1 Guide Line 12 1
127 04RLM017 R1 Guide Line 13 2
128 04RLM001 Column Sensor Line 1
129 04REM001 Lower Section of Safety Lock 1
130-EU 04ALM011 Power Cord 1
130-120 04ALM007 Power Cord 1
130-UK 04ALM023 Power Cord 1
131 04RLM003 Column Spring 1
132 04RLM004 Upper and Lower Controller Connection 1
133 04ARM003 Remote Control 1
134 03AFD023 Remote Control Lanyard 1
135 02ABS001 L-Shaped Hex Key 1
136 09ROI002 Silicone Oil 1
137 05RUG019 Specification 1
138 04RMG001 R1 US Magnetic Ring 1 1
139 04RMG002 R1 US Magnetic Ring 2 2
140 04RSW004 Overload Protection Device 1
140-120 04RSW002 Overload Protection Device 1
PARTS LIST
