Dynamic DX Power Module PMB User Manual

';3RZHU0RGXOH)HDWXUHV
5
 ';3RZHU0RGXOH)HDWXUHV
*HQHUDO)HDWXUHV
The PM has the following general features:
 Digital communications bus interface (DXBUS compatible), with remote
wake up and remote kill inputs via DXBUS;
 Two identical DXBUS sockets with protected 12A RMS maximum battery
power supply;
 Digital motor control;
 Completely programmable for parameters such as load compensation, motor
veer compensation, current limit level and dual or single Park Brakes;
 Protected against external events such as:
- reverse battery
- battery under and over voltage
- overloaded motor or Park Brakes
- external short circuits
- stalled motor;
 Extensive range of wheelchair system safety and protection features such as:
- open circuit motor detection
- open and short circuit Park Brake detection
- controlled speed reduction to a stop if a fault is detected;
 Electromagnetically compatible:
- low RF emissions
- low susceptibility to RF transmissions;
 Environmentally compatible (sealed to IP54);
 Built-in diagnostics with status LED and fault logging;
 Compact, rugged enclosure with robust mounting points;
 Approved by the German Safety Standards Authority TÜV.

Dynamic DX Power Module PMB Specifications

General

Brand	Dynamic
Model	DX Power Module PMB
Category	Control Unit
Language	English
