$SSHQGL[$$EEUHYLDWLRQV
72
$SSHQGL[$$EEUHYLDWLRQV
Abbreviation Expansion / Explanation
CANH Controller Area Network High line. One of the four wires
which make up the DXBUS.
CANL Controller Area Network Low line. One of the four wires that
make up the DXBUS.
CISPR Comite International Special des Perturbations
Radioelectriques
DX Dynamic Control Modular Mobility System
DXBUS The DX System communication CAN communication lines
plus power supply to DX Modules.
ESD Electrostatic Discharge
HHP Hand Held Programmer. The HHP can be used by both DX
System and all DlxxUxxx Controllers.
IEC International Electrotechnical Committee
IP54 Ingress Protection rating
ISO International Standards Organisation
LED Light Emitting Diode
LM Left Motor.
M1 The Left Motor and Park Brake connector, if the Left/Right
Motor Swap parameter set to ‘norm’
M2 The Right Motor and Park Brake connector, if the Left/Right
Motor Swap parameter set to ‘norm’
