Dyson AB 09 - Page 37

Water Valve
PCB ASSEMBLY
Grommet
Grommet Grommet
P7 LIVE P6 LIVE
1 4VF 1 4V
4 0V
4 0VF
P5 NEUTRAL P8 NEUTRAL
M16 Gland
J15
J3
J2 J14
Supplied In-Line Conn
2X UL1569 24AWG
COMS-PCB Loom
Assembly
4X UL2517 28AWG
2X UL1569
14AWG
2X UL1569
16AWG
3X UL2464
28AWG
Male
Connector
Assembly
Terminal Block
Mains Supply
Vacuum Motor
(DDM-V4)
Live
M
Neutral
Controller Wiring Assembly
4X UL2517 28AWG
PCB ASSEMBLY
CONTROLLER SINGLE
Solenoid-PCB Loom Assembly
2X UL1569 24AWG
J4
J8
J6 J5
J7
J10 J12
1 1 2 2 3 3 4 4 5 5 6 6
J9
2X UL1569 16AWG
Female Looms Female Looms
2X UL1569 26AWG
AB09 10 11 Wiring schematic
36
