Dyson DC21 - Page 30

Pre-filter
Assy
Bleed Valve
O-Ring
Bleed Valve
Housing
Cable Rewind
Actuator
Screw
Spring
Bleed Valve Cap
UMC
Spring
Pre-filter Cover
Assy
Switch Actuator
Spring
Cable Collar
Exhaust Seal
Lower
Pre-filter Seal
Upper Pre-filter Seal
PCB Bleed Pipe Elbow
Cable Rewind Bleed Pipe
Cable Rewind Bleed Pipe Elbow
27
service manual
Parts recognition
Wiring Harness
Motor Bucket
Fancase
Seal
Motor Plate
Motor Bucket
Mount
Motor Mount
Motor
Motor Bucket
Top
Motor assy
Pre-fi
Pre-filter cover & UMC assy
