E-bikes A1 - Packing List and Parts Identification (A2)

3 www.e-bikes.se
I. A2 Packing list and parts name instruction.
Saddle
Battery
Fork Pedal
Motor
Mudguards
Stem
Tire
Rim
Handlebar
Specifications:
FRAME
18,5+21” (50:50) Aluminum frame, max load: 120kgs; Engraved serial
number/article number on the bottom of BB shell
FORK
OMEGA 26", Suspension L/O lock out
SADDLE
VELO Leather
Brake Set:
FRONT and Back : SHIMANO ML375 disc-brake
Gear Set
SHIMANO RD-M410 7gears ALIVIO
Shift Lever
SLM410 3 *7speed
PEDAL
WellGo M-21 Aluminum
CRANK SET
ProWheel Swift
HANDLE BAR
GRIP
VELO
HANDLE BAR
ZOOM Professional
BATTERY
36V 10,4AH
，
SAMSUNG cell, bottle style, removable
CHARGER
36V 1.5A comply w/EN
DISPLAY
KINGMETER SW-LCD 36V, 5Speed
SENSOR
SH L:300MM,w/indicator,w/omagnetic disk, 12Points
CONTROLLER
LSW772 36V,max current 15A
MOTOR
H-Type Rear Motor 36V250W Line:120mm,without hall
