E-Mu Xboard 25 Brochure

E-MU 1010 PCI Card
24-bit/192 kHz
S/PDIF Coaxial
In and Out
ADAT In and Out
(192kHz compatible)
- switchable to optical
S/PDIF
EDI Connector to
E-MU MicroDock M
E-MU 0202 I/O Daughter Card
MIDI In/Out
Two 1/4" Balanced
Inputs (120dB SNR)
Two 1/4" Balanced
Outputs (120dB SNR)
Four 1/4" Balanced Inputs
(120dB SNR)
Turntable Input (with ground lug and
hardware RIAA preamp)
Two Full-size MIDI Inputs/Outputs
on Breakout Cable
External Power
Back
EDI Connector to E-MU
CardBus or 1010 PCI Card
Three Stereo 1/8" Speaker Outputs
(configurable from stereo to 5.1)
Six 1/4" Balanced Outputs
(120dB SNR)
24-bit/192kHz S/PDIF Coaxial In/Out
(Switchable to AES/EBU)
Two E-MU XTC
™
Ultra-low Noise Mic/Line Hi-Z Preamps with Soft
Limiter and 48V Phantom Power (-129.5dBu EIN)
Stereo Headphone Output
(118dB SNR)
24-bit/192kHz ADAT Optical
In/Out (Switchable to S/PDIF)
Front
MIDI In/Out
Two 1/4
Inputs (120dB SNR)
Two 1/4
Out
puts (120dB SNR)
2 1/4 " Analog Inputs
(24-bit/192kHz)
2 1/4 " Analog Outputs
(24-bit/192kHz)
Optical S/PDIF I/O
(24-bit/96kHz)
Coaxial S/PDIF I/O
(24-bit/96kHz)
MIDI I/O
PCI Digital Audio Systems
E-MU 0404 PCI Card
P C I
P C I
Digit a l Audi o Syste m
P C I
P C I
Production Tools Software Bundle includes: Cakewalk SONAR LE,
Steinberg’s Cubase LE and WaveLab Lite, Ableton Live 4 Lite for E-MU,
IK Multimedia AmpliTube LE and T-RackS EQ, Minnetonka diskWelder BRONZE,
SFX Machine LT, E-MU Proteus X LE Software Sound Module
P C I
P C I
Digit a l Audi o Syste m
Hardware Components:
• 1010 PCI Card
• MicroDock M
I/O Confi guration:
• Two E-MU XTC Mic/Line/Hi-Z preamps
(w/soft limiter and 48V phantom power)
• Four 1/4" Balanced Inputs
• Six 1/4" Balanced Outputs
• Turntable Input (w/ground lug and hardware RIAA preamp)
• 24-bit/192kHz ADAT In/Out (switchable to S/PDIF)
• 24-bit/192kHz coaxial S/PDIF In/Out (switchable to AES/EBU)
• Two sets of MIDI In/Out on breakout cable
• Three stereo 1/8" Speaker Outputs (confi gurable from stereo to 5.1)
• One Stereo Headphone Output
Hardware Components:
• 1010 PCI Card
• MicroDock
I/O Confi guration:
• Two E-MU XTC Mic/Line/Hi-Z preamps
(w/soft limiter and 48V phantom power)
• Four 1/4" Balanced Inputs
• Six 1/4" Balanced Outputs
• Turntable Input (w/ground lug and hardware RIAA preamp)
• 24-bit/192kHz ADAT In/Out (switchable to S/PDIF)
• 24-bit/192kHz coaxial S/PDIF In/Out (switchable to AES/EBU)
• Two sets of MIDI In/Out on breakout cable
• Three stereo 1/8" Speaker Outputs (confi gurable from stereo to 5.1)
• One Stereo Headphone Output
Production Tools Software Bundle includes: Cakewalk SONAR LE,
Steinberg’s Cubase LE and WaveLab Lite, Ableton Live 4 Lite for E-MU,
IK Multimedia AmpliTube LE and T-RackS EQ, Minnetonka diskWelder BRONZE,
SFX Machine LT, E-MU Proteus X LE Software Sound Module
Production Tools Software Bundle includes: Cakewalk SONAR LE,
Steinberg’s Cubase LE and WaveLab Lite, Ableton Live 4 Lite for E-MU,
IK Multimedia AmpliTube LE and T-RackS EQ, Minnetonka diskWelder BRONZE,
SFX Machine LT, E-MU Proteus X LE Software Sound Module
Hardware Components:
• 1010 PCI Card
• 0202 I/O Daughtercard
I/O Confi guration:
• Two 1/4" Balanced Inputs
• Two 1/4" Balanced Outputs
• 24-bit/192kHz ADAT In/Out (switchable to S/PDIF)
• 24-bit/192kHz S/PDIF In/Out (switchable to AES/EBU)
• MIDI In/Out
Hardware Components:
• 0404 PCI Card
I/O Confi guration:
• Two 1/4" Unbalanced Inputs
• Two 1/4" Unbalanced Outputs
• 24-bit/96kHz S/PDIF optical In/Out (switchable to AES/EBU)
• 24-bit/96kHz S/PDIF coaxial In/Out (switchable to AES/EBU)
• MIDI In/Out
Production Tools Software Bundle includes: Cakewalk SONAR LE,
Steinberg’s Cubase LE and WaveLab Lite, Ableton Live 4 Lite for E-MU,
IK Multimedia AmpliTube LE, Minnetonka diskWelder BRONZE (trial version),
SFX Machine LT, E-MU Proteus X LE Software Sound Module
P C I
P C I
Digital Audio System
Digital Audio System
MicroDock M
