Black Tiller Guard Removal
First - Remove the headlight first with a Phillips screwdriver as shown in photos. Then there will be a
total of 3 screws to be removed for this shroud to be removed, 2 of then on the inside and 1 on the
outside of it as well. ( Update Photos and Description )
Will There will be 3 screws that are holing
speedometer to the black tiller guard.
Remove all 3 with a Philips screw driver.
Key Note - The speedometer can be removed as well if needed once this has been
completed. A 10mm soket and rachet can also be used to remove the outside bolt.
