OPERATING
CONDITION
/MODE
TIMING
SEQUENCE
STATUS
RELAY LED
CH1
ON TIME RLY1 ON ON
OFF TIME RLY1 OFF OFF
CH2
ON TIME RLY2 ON ON
OFF TIME RLY2 OFF OFF
CH3
ON TIME RLY3 ON ON
OFF TIME RLY3 OFF OFF
CH4
ON TIME RLY4 ON ON
OFF TIME RLY4 OFF OFF
a) The Set time changed when timing in progress is effective for the next
cycle onwards (after the completion of the off time of ch4).
b) The Set time changed when S1-S2 is open is effective for the immediate
timing irrespective of hold/restart (i.e. Power is not interrupted).
c) The Range settings shall not be done in the forbidden area.
Technical Specification
Function Sequential timer with 4 channels.
Rated supply Voltage 240V AC
Operating voltage
range
± 10% of the rated voltage
Rated Frequency 50Hz ± 5%
Power consumption AC Approx. 20VA / 4W.
Control output
4 O/P'S (5A @ 250 VAC/28 VDC resistive)
Start Signal (S1, S2)
Potential free closure (CONTINUOUS).
On time range 0.1 to 1 S/M/H for each channel
Off time range 0.1 to 1 S/M/H for each channel
Setting accuracy ± 10 % max. w.r.t full scale ± 100 mSec
Repeat accuracy ± 1 % max. ± 100 mSec
Recovery Time
1Sec minimum
Variation due to
voltage change
± 2% max. ± 100 mSec
Variation due to
temperature change
± 5% max. ± 100 mSec
Variation due to
frequency change
± 2% max. ± 100 mSec
Ambient temperature
Operating : -10
˚
C to +55
˚
C
Storage : -25
˚
C to +80
˚
C
Humidity
MAX 85% RH @ 40
˚
C
Disposition
Once the product life is over, you may send Back the unit to
EAPL for disposition.
Contact
Electronic Automation Pvt. Ltd
#20, KHB Industrial area
Yelahanka
Bangalore -64
Ph:+91-80-28567561/2,/42802345
Customer care :Ph:+91-80-42802323
Email : info@eaplindiamail.com
www.eaplindia.com
OD RK AN 050011 REV 02/24-05-2018
