STRIPPING: Remember to check a small area first.
Operation is simple for both right and left handed people. Simply hold the steam plate flat against the wallpaper for
approx. 10 seconds. Now move the plate to the spot immediately next to the one just steamed - from which the
paper should now easily come away with a little help from a wall scraper. Working this way should enable continuous
paper removal although it may be necessary to steam for longer periods with some papers, or if not completely
removed first time. If unit requires refilling, unplug cord and allow to cool for at least 2 minutes before removing filler
cap -
Beware of steam. When finished, allow to cool completely and empty unit.
SAFETY CUT-OUT
A
safety cut-out is fitted to prevent overheating the element if the water boils low. If unit stops boiling during use this may be the
cause. Wait for 2 minutes before removing filler cap then re-fill with water. The cut-out will self reset and steam be produced again
within 5-15 minutes. The cut-out will not protect the element if a part filled unit is tilted during use in a way which enables
part of the element to be out of the water for longer than 15-20 seconds.
OTHER USES
Artex
®
Normally Artex
®
can be removed using the same method as for wallpaper although the steaming time will be longer.
CAUTION: Some textured finishes may contain asbestos which may be hazardous to health and which are subject to licensing
controls operated by the HSE (Health & Safety Executive).
Vinyl Floor Tiles
Vinyl floor tiles can also be removed if the plate is left long enough for the heat to penetrate the adhesive. Once the adhesive is hot it
softens and the tile can be peeled from the floor.
Sterilising Soil
To sterilise soil in seed trays or greenhouses rake the soil to obtain a fine surface. Leave the steam plate on
each section, for 2 to 2.5 minutes which should ensure that the steam has penetrated through the surface.
Killing Weeds
Steam will kill weeds on paths and patios without the use of chemicals. You will need to steam the weeds for 1
to 1.5 minutes in order to kill them.
SCRAPER
The scraper supplied with your unit has a reversible blade. To change the blade undo the two screws on the underside of the scraper
to free the blade and the retaining plate. Beware of sharp edges when handling the blade. Before refitting the blade and retaining
plate ensure that the roller is correctly seated. Replace the two screws to secure the blade. Always fit the protective cover to the
scraper when not in use. Packs of spare blades for the scraper are available from Earlex. Please contact our helpline on: 01483
454666 for further details.
SMALL STEAM PLATE
DANGER FROM STEAM. Always be aware that steam is being produced whilst the tool is in operation. Always wear a protective
glove when using. This tool can be used to strip wallpaper in awkward areas, ie around door frames and in corners etc. Use similarly
to the large steam plate, steaming one area whilst stripping a previously steamed area. This will ensure quick efficient removal of the
wallpaper.
Additionally you can remove creases from curtains, however before use you must check that the fabric will not be affected by steam
and always use a clean steam plate.
NEVER use on Draylon
®
.
TROUBLE SHOOTING
Unit Fails to Boil
The unit has probably not been left for long enough to cool - refer to section on safety cut-out. Check the fuse in the plug is sound
and is rated at 13 amps. If using an extension lead check that it is rated at a minimum of 10 amps and it is fully unwound.
Unit Leaks Steam from Pressure Relief Valve
The pressure relief valve is a special low pressure valve and cannot be replaced by any other valve. If steam is leaking from the
valve, the most likely cause is a blockage in the hose.
Allow the hose to cool then remove the hose and check for any blockage.
Always check the inlet in the tool you are using.
UNDER NO CIRCUMST
ANCES FORCE THE V
AL
VE SHUT
. THIS IS OPERA
TING FOR
YOUR PROTECTION.
IF YOU REQUIRE FURTHER ASSISTANCE PLEASE CONTACT OUR HELPLINE ON:
Tel: 01483 454666 Fax: 01483 454548 email: enquiries@earlex.co.uk
Opening Hours: Monday-Friday 08.30-18.00 (Excluding Bank Holidays)
W
ebsite:
www
.earlex.co.uk
