EAST OAK PPS23002 - Assembly: Connecting Frame; Connect the Crossbars; Install the Support Feet

76 EASTOAK.COM3-PERSON OUTDOOR PATIO PORCH SWING OWNER’S MANUAL
2
1
Install the support feet
Connect the crossbars
Align the screw holes, install screws with a
spanner, pre-install the two screws on each foot
before tightening them fully, and then put on the
plastic cap. Install the four support feet in the
same way.
Connect the crossbars A1 and A2, align their
screw holes, install screws with a spanner,
pre-install the two screws before tightening
them fully, and then put on the plastic cap.
I
I
S
I
B
C
A1
A1
A2
A2
X
X (2PCS)
AA
(1PC)
T (1PC)
BB
(1PC)
U (1PC)
S (8PCS)
AA
BB
AA
AA
X
M8*60mm
A2 (1PC)
A1 (1PC)
S
M6*20mm
B (2PCS)
I (4PCS)
C (2PCS)
Warning Tips: Since the support feet are deep and the
screws are short, use a hex wrench (AA) to secure the
screw heads before tightening the screws.
