Connect the
connecting rods
Connect the rods E1 and E2, align their screw
holes, install screws fully with a spanner and
then put on the plastic cap. Connect the other
connecting rod in the same way.
E1
E2
T
T (2PCS)
E1 (2PCS)
E2 (2PCS)
T
M6*32mm
AA
(1PC)
AA
(1PC)
BB
(1PC)
BB
(1PC)
AA
AA
BB
6
Install the connecting rods
Connect the assembled rods E1 and E2 with the
installed outer frames, align their screw holes, install
screws with a spanner, pre-install the four screws on
the two iron frames before tightening them fully, and
then put on the plastic caps.
W
BB
W
M6*62mm
W (8PCS)
To Next Page
