Eaton DS7 Series User Manual

3
Instructional Lea et IL03901003E
Effective May 2011
DS7 series soft start controllers, Frame 1 (4–12A)
EATON CORPORATION www.eaton.com
Product selection—horsepower ratings
Please refer to Application Note AP03901006E for additional information on proper size selection.
10 second ramp, one start per hour, 300% current limit at 40°C Table 4.

Rated
Current
(A)
Motor Power (hp) Maximum
Allowable
Breaker Size
Maximum
Allowable
Fuse Size
Recommended
XTOB Overload
(Direct Connect)

Recommended
XTOE Overload

MMP

Connection
Kit to MMP
Catalog
Number200V 230V 480V
3.7 0.75 0.75 2 HFD3015 15A Class RK5 XTOB004BC1 XTOE005BCS XTPR004BC1 XTPAXTPCB DS7-340SX004NO-N

DS7-342SX004NO-N

6.9 1.5 2 3 HFD3015 15A Class RK5 XTOB006BC1

XTOE020BCS XTPR6P3BC1 XTPAXTPCB DS7-340SX007NO-N

DS7-342SX007NO-N

7.8 2 2 5 HFD3020 20A Class RK5 XTOB010BC1 XTOE020BCS XTPR010BC1 XTPAXTPCB DS7-340SX009NO-N

DS7-342SX009NO-N

11 3 3 7.5 HFD3030 20A Class RK5 XTOB012BC1 XTOE020BCS XTPR012BC1 XTPAXTPCB DS7-340SX012NO-N

DS7-342SX012NO-N

10 second ramp, one start per hour, 400% current limit at 40°C Table 5.

Rated
Current
(A)
Motor Power (hp) Maximum
Allowable
Breaker Size
Maximum
Allowable
Fuse Size
Recommended
XTOB Overload
(Direct Connect)

Recommended
XTOE Overload

MMP

Connection
Kit to MMP
Catalog
Number200V 230V 480V
3 0.5 0.5 1.5 HFD3015 15A Class RK5 XTOB004BC1 XTOE005BCS XTPR004BC1 XTPAXTPCB DS7-340SX004NO-N

DS7-342SX004NO-N

4.8 1 1 3 HFD3015 15A Class RK5 XTOB006BC1

XTOE020BCS XTPR6P3BC1 XTPAXTPCB DS7-340SX007NO-N

DS7-342SX007NO-N

6.9 1.5 2 3 HFD3020 20A Class RK5 XTOB006BC1 XTOE020BCS XTPR6P3BC1 XTPAXTPCB DS7-340SX009NO-N

DS7-342SX009NO-N

9 2 2 5 HFD3030 20A Class RK5 XTOB010BC1 XTOE020BCS XTPR010BC1 XTPAXTPCB DS7-340SX012NO-N

DS7-342SX012NO-N

Product selection—kW ratings according to IEC 60947-4-2
Please refer to Application Note AP03901006E for additional information on proper size selection.
10 second ramp, one start per hour, 300% current limit at 40°C Table 6.

Rated
Current
(A)
Motor Power (kW) Maximum
Allowable
Breaker Size
Maximum
Allowable
Fuse Size
Recommended
XTOB Overload
(Direct Connect)

Recommended
XTOE Overload

MMP

Connection
Kit to MMP
Catalog
Number230V 400V
3.8 0.75 1.5 HFD3015 15A Class RK5 XTOB004BC1 XTOE005BCS XTPR004BC1 XTPAXTPCB DS7-340SX004NO-N

DS7-342SX004NO-N

7 1.5 3 HFD3015 15A Class RK5 XTOB006BC1

XTOE020BCS XTPR6P3BC1 XTPAXTPCB DS7-340SX007NO-N

DS7-342SX007NO-N

9 2.2 4 HFD3020 20A Class RK5 XTOB010BC1 XTOE020BCS XTPR010BC1 XTPAXTPCB DS7-340SX009NO-N

DS7-342SX009NO-N

12 3 5.5 HFD3030 20A Class RK5 XTOB012BC1 XTOE020BCS XTPR012BC1 XTPAXTPCB DS7-340SX012NO-N

DS7-342SX012NO-N

10 second ramp, one start per hour, 400% current limit at 40°C Table 7.

Rated
Current
(A)
Motor Power (kW) Maximum
Allowable
Breaker Size
Maximum
Allowable
Fuse Size
Recommended
XTOB Overload
(Direct Connect)

Recommended
XTOE Overload

MMP

Connection
Kit to MMP
Catalog
Number230V 400V
2.5 0.33 1 HFD3015 15A Class RK5 XTOB004BC1 XTOE005BCS XTPR004BC1 XTPAXTPCB DS7-340SX004NO-N

DS7-342SX004NO-N

3.8 0.75 1.5 HFD3015 15A Class RK5 XTOB006BC1

XTOE020BCS XTPR6P3BC1 XTPAXTPCB DS7-340SX007NO-N

DS7-342SX007NO-N

7 1.5 3 HFD3020 20A Class RK5 XTOB006BC1 XTOE020BCS XTPR6P3BC1 XTPAXTPCB DS7-340SX009NO-N

DS7-342SX009NO-N

9 2.2 4 HFD3030 20A Class RK5 XTOB010BC1 XTOE020BCS XTPR010BC1 XTPAXTPCB DS7-340SX012NO-N

DS7-342SX012NO-N

Notes
Actual motor FLAs vary. Verify these devices cover the motor specific FLA.

Selections are based on motor FLA value at 480V.

Not to be used with 230V.

24 Vac/Vdc device.

120/230 Vac device.


Eaton DS7 Series Specifications

General

Type	Soft Starter
Control Voltage	24 V DC
Input Frequency	50/60 Hz
Protection Class	IP20
Cooling Method	Natural Convection
Protection Features	Overload
Communication	Modbus RTU
Operating Temperature	-25 to 60°C
Dimensions	Varies by model
Weight	Varies by model
