ELC Programming Manual
FOR MORE INFORMATION VISIT: WWW.EATON.COM MN05003003E
2-26
SM
Function
ELC
-PB
ELCB
-PB
ELC
-PC
-PA
-PH
ELCM
-PH
-PA
ELC
-PV
OFF
Ø
ON
STOP
Ø
RUN
RUN
Ø
STOP
Type Latched
Factory
setting
Enabling the mask and alignment mark
function on I600/I601(X6) corresponding
to Y2
- - Y -
M1158
Enable CH2 pulse output pause (ramp
down) function when interrupt signal is
triggered from X2
- - - Y
OFF OFF - R/W NO OFF
M1159
Enable CH3 pulse output pause (ramp
down) function when interrupt signal is
triggered from X3
- - - Y OFF OFF - R/W NO OFF
M1161
8/16 bits mode (ON = 8 bit mode)
Y Y Y Y OFF - - R/W NO OFF
M1162
Switching between decimal integer and
binary floating point for SCLP instruction
ON: binary floating point; OFF: decimal
integer
Y Y Y Y OFF - - R/W NO OFF
M1164
Enable flash ROM access function
according to the value set in D1064
(M1164 resets automatically when data
access is completed)
- - - Y OFF - - R/W NO OFF
M1165
When ON, the program and password on
flash will be copied to the ELC when the
ELC is powered.
- - - Y - - - R/W YES OFF
M1166
When ON, the recipe on flash will be
copied to the ELC when the ELC is
powered.
- - - Y - - - R/W YES OFF
M1167
HKY input is 16 bits mode
- Y Y Y OFF - - R/W NO OFF
M1168
SMOV working mode indication
- Y Y Y OFF - - R/W NO OFF
M1169
Selecting PWD modes
- - - Y
OFF - - R/W NO OFF
M1170
Enabling single step execution
- - - Y
OFF - - R/W NO OFF
M1171
Single step execution
- - - Y
OFF - - R/W NO OFF
M1172
2-phase pulse output switch (on is start)
- Y - - OFF OFF OFF R/W NO OFF
M1173
ON is continuous output switch
- Y - - OFF - - R/W NO OFF
M1174
Output pulse number attained flag
- Y - - OFF OFF OFF R/W NO OFF
M1175
Losing ELC parameter data
- - - Y
- - - R YES OFF
M1176
Losing the data in the ELC program
- - - Y
- - - R YES OFF
M1178
VR0 Variable resistor enable
- Y - Y OFF - - R/W NO OFF
M1179
VR1 Variable resistor enable
- Y - Y OFF - - R/W NO OFF
M1181
ELC-PH/PC: Reset the high speed
counting value from X0 when interrupt is
triggered from X2/ I201. (The counting
value will be catched by D1180/D1181
before it is reset immediately).
- Y - - OFF OFF - R/W NO OFF
M1182
ELC-PH/PC: Reset the high speed
counting value from X1 when interrupt is
triggered from X3/ I301. (The counting
value will be move to D1198/D1199
before it is reset immediately).
- Y - - OFF OFF - R/W NO OFF
