Eaton EX RT 5 3:1 - Installation in tower configuration

Page 12 - 34007724EN/AD
2. Installation
2.2 Installation in tower configuration
Use the tower stand template provided with the battery module.
1
3
4
2
1
4
3
2
4
4
Follow steps 1 to 4 to adjust the tower stands for the upright position.
Always keep 150 mm free space behind the UPS rear panel.
The distance between the tower stands should be 450 mm.
