MVX9000 Parameter Listing
B-10 MVX9000 User Manual
Parameter Tables
Table B-5: 60 — MOTOR CONTROL
Modbus Groups Page # Description Range Default
User
Settings
0400H 60.01 5-50 Motor Rated Current 30 to 120% FLA
0401H 60.02 5-50 Motor No-Load
Current
00 to 99% 0.4*
FLA
0402H 60.03 5-50 Motor Auto Tuning 00: Disable 00
01: DC test
02: DC test and no load test
0403H 60.04 5-50 Motor’s Stator
Resistance
(calculated via auto
tune or entered
manually)
00 to 65535 m Ohms 00
0404H 60.05 5-51 DC Braking Current
Level
00 to 100% 00
0405H 60.06 5-51 DC Braking Time
upon Start-up
0.0 to 5.0 sec 0.0
0406H 60.07 5-51 DC Braking Time
upon Stopping
0.0 to 25.0 sec 0.0
0407H 60.08 5-52 Frequency-point for
DC Braking
0.0 to 60.0 Hz 0.0
0408H 60.09 5-52 Torque
Compensation
00 to 10 00
0409H 60.10 5-53 Slip Compensation 0.00 to 10.00 0.0
040AH 60.11 5-53 PWM Carrier
Frequency
115V/230V/460V: 1 to 15 KHz 9
575V: 1 to 10 KHz 6
