Fuse Specification
C-2 MVX9000 User Manual
Accessories
Fuse Specification
Smaller fuses than those shown in the table are permitted.
Table C-1: Fuse Specification
Recommended Fuses for UL approval.
Equivalent fuse types = J class, CC class, T class and Type BS88 with a 600V limit.
Model
Input
Current
(A)
Output
Current
(A)
Line Fuse
MMP Catalog
Number
Recommended
Contactor
Catalog NumberI(A) Buss
F25A0-1 6 1.6 15 JJN-15 XTPR010BC1 XTCE009B_
F50A0-1 9 2.5 30 JJN-30 XTPR016BC1 XTCE012B_
001A0-1 16 4.2 50 JJN-50 XTPR020BC1 XTCE025C_
F50A0-2 (1p) 6.3 2.5 25 JJN-25 XTPR6P3BC1 XTCE009B_
F50A0-2 (3p) 3.2 2.5 10 JJN-10 XTPR004BC1 XTCE009B_
001A0-2 (1p) 11.5 5 45 JJN-45 XTPR016BC1 XTCE012B_
001A0-2 (3p) 6.3 5 20 JJN-20 XTPR010BC1 XTCE009B_
002A0-2 (1p) 15.7 7 60 JJN-60 XTPR020BC1 XTCE025C_
002A0-2 (3p) 9 7 25 JJN-25 XTPR016BC1 XTCE012B_
003A0-2 (1p) 27 10 100 JJN-100 XTPR032BC1 XTCE032B_
003A0-2 (3p) 15 10 40 JJN-40 XTPR010BC1 XTCE018C_
005A0-2 19.6 17 60 JJN-60 XTPR025BC1 XTCE025C_
007A0-2 28 25 100 JJN-100 XTPR032BC1 XTCE032C_
001A0-4 4.2 3 10 JJS-10 XTPR004BC1 XTCE009B_
002A0-4 5.7 4 15 JJS-15 XTPR6P3BC1 XTCE009B_
003A0-4 6 5 20 JJS-20 XTPR010BC1 XTCE009B_
005A0-4 8.5 8.2 30 JJS-30 XTPR016BC1 XTCE018C_
007A0-4 14 13 50 JJS-50 XTPR016BC1 XTCE025C_
010A0-4 23 18 70 JJS-70 XTPR025BC1 XTCE025C_
001A0-5 2.4 1.7 5 JJS-6 XTPR6P3BC1 XTCE007B_
002A0-5 4.2 3.0 10 JJS-10 XTPR6P3BC1 XTCE007B_
003A0-5 5.9 4.2 15 JJS-15 XTPR6P3BC1 XTCE007B_
005A0-5 7.0 6.6 15 JJS-15 XTPR010BC1 XTCE007B_
007A0-5 10.5 9.9 20 JJS-20 XTPR012BC1 XTCE012B_
010A0-5 12.9 12.2 30 JJS-50 XTPR016BC1 XTCE015B_
