6 Technical Data
6.8 Radio inter ference suppression filter
DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com 155
Table 30: Assigned radio interference suppression filter (three-phase)
Device Type
Frame
size
Input
current
Radio interference suppression filter, three-phase
Max. mains voltage U
LN
: 520 V +0%, 50/60 Hz ±10%
Max. ambient temperature: 50
o
C
Type rated
operational
current
Leakage
current
(IEC38, ±10 %)
Maximum motor cable length
based on RFI class
C1 C2 C3
I
LN
I
e
I
PE
l l l
A A mA mA mA mA
Mains voltage 230 V
Supply voltage (50/60 Hz) U
LN
200 (-10 %) - 240 (+10 %) V
U
e
230 V AC, three-phase / U
2
230 V AC, three-phase
DC1-322D3NN-A20N
FS1 3.4 DX-EMC34-008-FS1 8 21 25 50 50
DX-EMC34-008-FS1-L 8 6 25 100 150
DX-EMC34-008 8 21 25 50 75
DX-EMC34-008-L 8 6 5 25 50
DC1-324D3NN-A20N
FS1 5.6 DX-EMC34-008-FS1 8 21 25 50 50
DX-EMC34-008-FS1-L 8 6 25 100 175
DX-EMC34-008 8 21 25 50 75
DX-EMC34-008-L 8 6 5 25 50
DC1-327D0NN-A20N
FS1 9.5 DX-EMC34-016 16 21 25 75 125
DX-EMC34-016-L 16 6 15 25 50
DC1-327D0NB-A20N
FS2 8.9 DX-EMC34-011-FS2 11 21 50 75 75
DX-EMC34-011-FS2-L 11 6 25 100 175
DX-EMC34-016 16 21 25 50 75
DX-EMC34-016-L 16 6 15 25 50
DC1-32011NB-A20N
FS2 12.1 DX-EMC34-016 16 21 25 75 100
DX-EMC34-016-L 16 6 15 25 50
DC1-32018NB-A20N
FS3 20.9 DX-EMC34-025-FS3 25 29 50 100 125
DX-EMC34-025-FS3-L 25 6.5 25 50 75
DX-EMC34-030 30 29 25 50 75
DX-EMC34-030-L 30 6.5 5 25 50
DC1-32024NB-A20N
FS3 26.4 DX-EMC34-030 30 29 25 50 75
DX-EMC34-030-L 30 6.5 5 25 50
DC1-32030NB-A20N
FS4 33.3 DX-EMC34-042 42 29 25 50 75
DX-EMC34-042-L 42 6.5 5 25 50
DC1-32046NB-A20N
FS4 50.1 DX-EMC34-055 55 29 25 50 75
DX-EMC34-055-L 55 6.5 5 25 50
