Eaton PowerXL DG1 - Figure 49. FR5 Dimension Drawing

87
Appendix C—Dimension drawings
POWERXL SERIES VFD MN040002EN—February 2018 www.eaton.com
Approximate dimensions in Inches (mm)
Figure 49. FR5 Dimension drawing
%$&.
5(6(7
OK
5(027( 581 )$8/7
/2&$/
5(0
%$&.
5(6(7
OK
5(027(581)$8/7
/2&$/
5(0
30.51 (775.0)
Ø0.79 (Ø20.0)
11.10 (282.0)
34.98 (888.5)
A = Air gap around drive
(between drive and cabinet)
B = Space between two drives
C = Free space above drive
D = Free space below drive
Minimum Dimensions
C 11.81
(300.0)
D 7.87
(200.0)
1.14
(29.0)
11.34 (288.0)
8.66 (220.0)
Ø0.35
(Ø9.0)
Ø0.71
(Ø18.0)
Ø0.89
(Ø22.5)
Ø2.95
(Ø75.0)
5.51
(140.0)
2.52
(64.0)
4.21
(107.0)
7.76
(197.0)
29.65
(753.0)
1.57
(40.0)
4.09
(104.0)
3.83
(97.2)
22.57
(573.3)
29.65
(753.0)
3.80
(96.5)
8.66
(220.0)
1.57
(40.0)
8.66
(220.0)
Ø0.35
(Ø9.0)
Type 1/12 ULIP21/IP54 Metric
140.0
64.0
197.0
107.0
2–Ø75.0
3–Ø25.3
40.0
40.0
104.0
B 6.30 (160.0)
A 3.15 (80.0)
13.41
(340.7)
27.83 (707.0)
