Appendix D—Safety instructions for UL and cUL
POWERXL SERIES VFD MN040002EN—February 2018 www.eaton.com
Branch circuit short circuit protection
Integral solid-state short circuit protection does not provide
branch circuit protection. Branch circuit protection must be
provided in accordance with the National Electrical Code and
any additional local codes.
480 V Drive Series are suitable for use on a circuit capable of
delivering not more than 100,000 rms symmetrical amperes,
500 volts maximum, when protected by UL and cUL/CSA
Listed devices mentioned below with an A.I.C. rating of
100kA minimum.
•
Class RK5, Class J, Class T or equivalent fuses
•
Thermal-magnetic circuit breakers
•
Magnetic only circuit breakers (Eaton Type HMCP)
Refer to the following information for recommended ratings.
See Table 76.
Table 78. Protection ratings—480 V drive series
Frame
size
DG1
catalog number
DH1
catalog number
Maximum
fuse rating

Maximum
thermal-magnetic
breaker rating

Magnetic only circuit breakers
Maximum magnetic
breaker rating

Maximum rated
Eaton type HMCP

0 DG1-342D2EB-C20C DH1-343D3EB-C20C

600 V, 10 A 480 V, 15 A 480 V, 7 A HMCP007C0C
DG1-343D3EB-C20C DH1-344D3EB-C20C

600 V, 10 A 480 V, 15 A 480 V, 15 A HMCP015E0C
DG1-344D3EB-C20C DH1-345D6EB-C20C

600 V, 15 A 480 V, 15 A 480 V, 15 A HMCP015E0C
DG1-345D6EB-C20C DH1-347D6EB-C20C

600 V, 15 A 480 V, 15 A 480 V, 25A HMCP025D0C
1 DG1-342D2xx-xxxx DH1-343D3XX-CXXC 600 V, 10 A 480 V, 15 A 480 V, 7 A HMCP007C0C
DG1-343D3xx-xxxx DH1-344D3XX-CXXC 600 V, 10 A 480 V, 15 A 480 V, 15 A HMCP015E0C
DG1-344D3xx-xxxx DH1-345D6XX-CXXC 600 V, 15 A 480 V, 15 A 480 V, 15 A HMCP015E0C
DG1-345D6xx-xxxx DH1-347D6XX-CXXC 600 V, 15 A 480 V, 15 A 480 V, 25 A HMCP025D0C
DG1-347D6xx-xxxx DH1-349D0XX-CXXC 600 V, 15 A 480 V, 15 A 480 V, 25 A HMCP025D0C
DG1-349D0xx-xxxx DH1-34012XX-CXXC 600 V, 15 A 480 V, 15 A 480 V, 25 A HMCP025D0C
2 DG1-34012xx-xxxx DH1-34016XX-CXXC 600 V, 35 A 480 V, 35 A 480 V, 50 A HMCP050K2C
DG1-34016xx-xxxx DH1-34023XX-CXXC 600 V, 60 A 480 V, 60 A 480 V, 70 A HMCP070M2C
DG1-34023xx-xxxx DH1-34031XX-CXXC 600 V, 80 A 480 V, 80 A 480 V, 100 A HMCP100R3C
3 DG1-34031xx-xxxx DH1-34038XX-CXXC 600 V, 90 A 480 V, 90 A 480 V, 100 A HMCP100R3C
DG1-34038xx-xxxx DH1-34046XX-CXXC 600 V, 100 A 480 V, 100 A 480 V, 100 A HMCP100R3C
DG1-34046xx-xxxx DH1-34061XX-CXXC 600 V, 150 A 480 V, 150 A 480 V, 100 A HMCP100R3C
4 DG1-34061xx-xxxx DH1-34072XX-CXXC 600 V, 175 A 480 V, 175 A 480 V, 250 A HMCP250W5C
DG1-34072xx-xxxx DH1-34087XX-CXXC 600 V, 200 A 480 V, 200 A 480 V, 250 A HMCP250W5C
DG1-34087xx-xxxx DH1-34105XX-CXXC 600 V, 300 A 480 V, 300 A 480 V, 400 A HMCP400W5C
5 DG1-34105xx-xxxx DH1-34140XX-CXXC 600 V, 350 A 480 V, 350 A 480 V, 400 A HMCP400N5C
DG1-34140xx-xxxx DH1-34170XX-CXXC 600 V, 400 A 480 V, 400 A 480 V, 400 A HMCP400N5C
DG1-34170xx-xxxx DH1-34205XX-CXXC 600 V, 400 A 480 V, 400 A 480 V, 400 A HMCP400N5C
6 DG1-34205xx-xxxx DH1-34261XX-CXXC 600 V, 400 A 480 V, 400 A 480 V, 400 A HMCP400N5C
DG1-34245xx-xxxx DH1-34310XX-CXXC 600 V, 400 A 480 V, 400 A 480 V, 400 A HMCP400N5C
otes: N  These ratings are based off the largest wire size designed for the given Frame. Please verify your
protectionprotects your wire sizing. See Appendix B for recommended fuse and wire size.
 IP20 FR0 will be available in June 2018.
