Chapter 1—PowerXL Series overview
POWERXL SERIES VFD MN040002EN—February 2018 www.eaton.com
Table 12. Frame 2
Catalog number Catalog number Catalog number
Description
Ё᭛ᦣ䗄˖ 230 V 480 V 600 V
Standard Keypad DG1󰵼ޚ䬂Ⲭ DXG-KEY-LCD DXG-KEY-LCD DXG-KEY-LCD
Control module kit with keypad DG1᥻ࠊ῵ഫঞ䬂Ⲭ༫ӊ DXG-SPR-CTRLKIT DXG-SPR-CTRLKIT DXG-SPR-CTRLKIT
Control module kit without keypad DG1᥻ࠊ῵ഫ DXG-SPR-CTRLBOARD DXG-SPR-CTRLBOARD DXG-SPR-CTRLBOARD
Software kit (software, cable, manual) DG1䕃ӊ༫ӊ˄䕃ӊˈ㒓㓚ˈ䇈ᯢк˅ DXG-ACC-SOFTWARE DXG-ACC-SOFTWARE DXG-ACC-SOFTWARE
Type 1/IP21 standard cover Type1/IP21ࠡ䴶ᵓ DXG-SPR-FR2CVR DXG-SPR-FR2CVR DXG-SPR-FR2CVR
EMI board EMIᵓ DXG-SPR-2FR2EB DXG-SPR-4FR2EB DXG-SPR-5FR2EB
Type 12/IP54 kit Type1/IP54༫ӊ DXG-ACC-FR2N12KIT DXG-ACC-FR2N12KIT DXG-ACC-FR2N12KIT
Main power board FR1Џࡳ⥛ᵓ DXG-SPR-2FR2MPB DXG-SPR-4FR2MPB DXG-SPR-5FR2MPB
Control board cover DXG-SPR-BCOVER DXG-SPR-BCOVER DXG-SPR-BCOVER
Main fan kit

DXG-SPR-FR2FAN DXG-SPR-FR2FAN DXG-SPR-FR2FAN
Control fan DXG-SPR-FR2CF DXG-SPR-FR2CF DXG-SPR-FR2CF
Bus capacitor DXG-SPR-2FR2BC DXG-SPR-4FR24BC DXG-SPR-5FR24BC
IGBT module DXG-SPR-FR2IGBT DXG-SPR-FR2IGBT DXG-SPR-5FR2IGBT
Middle chassis cover DXG-SPR-FR2MCC DXG-SPR-FR2MCC DXG-SPR-FR2MCC
Outer housing DXG-SPR-FR2OH DXG-SPR-FR2OH DXG-SPR-5FR2OH
UL conduit plate DXG-SPR-FR2CPUL DXG-SPR-FR2CPUL DXG-SPR-FR2CPUL
IEC conduit plate DXG-SPR-FR2CPIEC DXG-SPR-FR2CPIEC DXG-SPR-FR2CPIEC
Type 12 grommet DXG-SPR-FR2GRN12 DXG-SPR-FR2GRN12 DXG-SPR-FR2GRN12
Terminal block DXG-SPR-FR2TB DXG-SPR-FR2TB DXG-SPR-FR2TB
Table 13. Frame 3
Catalog number Catalog number Catalog number
Description
Ё᭛ᦣ䗄˖ 230 V 480 V 600 V
Standard keypad DG1󰵼ޚ䬂Ⲭ DXG-KEY-LCD DXG-KEY-LCD DXG-KEY-LCD
Control module kit with keypad DG1᥻ࠊ῵ഫঞ䬂Ⲭ༫ӊ DXG-SPR-CTRLKIT DXG-SPR-CTRLKIT DXG-SPR-CTRLKIT
Control module kit without keypad DG1᥻ࠊ῵ഫ DXG-SPR-CTRLBOARD DXG-SPR-CTRLBOARD DXG-SPR-CTRLBOARD
Software kit (software, cable, manual) DG1䕃ӊ༫ӊ˄䕃ӊˈ㒓㓚ˈ䇈ᯢк˅ DXG-ACC-SOFTWARE DXG-ACC-SOFTWARE DXG-ACC-SOFTWARE
Type 1/IP21 standard cover Type1/IP21ࠡ䴶ᵓ DXG-SPR-FR3CVR DXG-SPR-FR3CVR DXG-SPR-FR3CVR
EMI board EMIᵓ DXG-SPR-2FR3EB DXG-SPR-4FR3EB DXG-SPR-5FR3EB
Drive board
偅ࡼᵓ
DXG-SPR-2FR3DB DXG-SPR-4FR3DB DXG-SPR-5FR3DB
Main power board FR1Џࡳ⥛ᵓ DXG-SPR-2FR3MPB DXG-SPR-4FR3MPB DXG-SPR-5FR3MPB
Control board cover DXG-SPR-BCOVER DXG-SPR-BCOVER DXG-SPR-BCOVER
Main fan kit

DXG-SPR-FR3FANKIT DXG-SPR-FR3FANKIT DXG-SPR-FR3FANKIT
Main fan DXG-SPR-FR3FAN DXG-SPR-FR3FAN DXG-SPR-FR3FAN
Control fan DXG-SPR-FR34CF DXG-SPR-FR34CF DXG-SPR-FR34CF
Bus capacitor DXG-SPR-FR3BC DXG-SPR-FR3BC DXG-SPR-5FR3BC
Output board DXG-SPR-FR3OB DXG-SPR-FR3OB DXG-SPR-5FR3OB
Middle chassis cover DXG-SPR-FR3MCC DXG-SPR-FR3MCC DXG-SPR-FR3MCC
Outer housing DXG-SPR-FR3OH DXG-SPR-FR3OH DXG-SPR-FR3OH
UL conduit plate DXG-SPR-FR3CPUL DXG-SPR-FR3CPUL DXG-SPR-FR3CPUL
IEC conduit plate DXG-SPR-FR3CPIEC DXG-SPR-FR3CPIEC DXG-SPR-FR3CPIEC
Type 12 grommet DXG-SPR-FR3GRN12 DXG-SPR-FR3GRN12 DXG-SPR-FR3GRN12
Terminal block DXG-SPR-FR3TB DXG-SPR-FR3TB DXG-SPR-FR3TB

Factory recommended spare parts.
