Read/write function block data
For more information visit: www.EatonElectrical.comMN05013001E 177
Table 114: Index 1 - Mode/Parameters
Mode Data 1 Operating mode
0 On-delayed
1 On-delayed with random setpoint
2 Off-delayed
3 Off-delayed with random setpoint
4 On and off delayed
(two time setpoints)
5 On and off delayed each with random
setpoint (two time setpoints)
6 Impulse transmitter
7 Flashing relay (two time setpoints)
8 Off-delayed, retriggerable
9 Off-delayed with random setpoint,
retriggerable
Para-
meters
Data 3 Operating mode
0 S (milliseconds)
1 M:S (seconds)
2 H:M (minutes)
