Read/write function block data
For more information visit: www.EatonElectrical.comMN05013001E 179
Table 115: Operand overview
Table 116: Index 0 – Bit IO
Index
(hex)
Operand Read Write
00 Bit IO, J Table 116 ×
01 Mode/Parameter – –
02 Input value I1 × c
1
03 Upper limit value SH × c
1
04 Lower limit value SL × c
1
05 Output value: outputs the
value present at input I1
within the set limits.
QV ×
1) The value can only be written if it is assigned to a constant in the
program.
Bit 7 6 5 4 3 2 1 0
FB output Data 3
– – – – – – – EN
1
1) Activates the function block on status 1.
