SLX9000 Adjustable Frequency Drives User Manual
3-6 For more information visit: www.eaton.com
MN04003020E
January 2009
Table 3-5: Mounting Procedure
1 Make sure that the plastic bag you
have received contains all necessary
components.
2 Open the cover of the drive.
3 Remove the cable cover. Observe the
places for:
a) the grounding terminals (MF4/MF5)
b) the grounding cable clamps (MF6,
FR7, FR8)
