5-16
(0
(2)
(3)
(4)
No high voltage. Probable causes:
(a) Q10 and/or ТІ defective.
(b) 0103 defective.
(c) A102 inoperative.
(d) CRIO defective.
(e) С17 defective. I
(f) HV control (R17) defective.
High voltage too high. Probable causes:
(a) A102 inoperative.
(b) 0103 defective.
(c) C17 defective.
(d) R12 defective.
No HV output (computer does not display high voltage).
(a) A102 inoperative.
(b) Q104 defective.
(c) 0105 defective.
(d) Broken wire in ribbon cable.
(e) Damaged PC board. |
(D Bad connection Al pin 12 to socket.
(g) Al inoperative.
Fluctuating high voltage (see note above). Probable causes:
(а) СК104 defective.
(b) А102 inoperativc.
(c) К12 defective.
ESPI.MAN/February 1992
