DESIG PART
R2 Resistor
R3,R101 Resistor
R4 Resistor
R20 Resistor
R10 Resistor
RII Resistor
R12 Voltage Divider
R13 Resistor
R14 Resistor
R15 Potentiometer
R16, R17 Potentiometer
R18 Potentiometer
R21,R109, Resistor
R113, R151
R102 Resistor
R103 Resistor
R104 Resistor
R105, Resistor
R106 Resistor
R108, Resistor
R115
R110 Resistor
КІП, Resistor
R120,R121,
R127,R140
R112 Resistor
R114 Resistor
R116 Resistor
R117 Resistor
ESPI.MAN/February 1992
DESCRIPTION
2.4k, 5%, 1/8 W,
carbon film
12 Q, 5%, 1/8 W,
carbon film
270 Q, 5%, 1/8 W,
carbon film
1k, 5%, 1/8 W,
carbon film
270 О, 5%, 1/4 W,
carbon film
10M, 5%, 1/4 W,
carbon film
1000M/1M, 5%
100k, 5%, 1/4 W,
carbon film
22 О, 5%, 1/4 W,
carbon film
500К
50К
25К
47k, 5%, 1/8 W,
carbon film
3.0M, 5%, 1/8 W,
carbon film
910k, 5%, 1/8 W,
carbon film
20k, 5%, 1/8 W,
carbon film
75К, 5%, 1/8 W,
carbon film
18k, 5%, 1/8 W,
carbon film
200k, 5%, 1/8 W,
carbon film
30k, 5%, 1/8 W,
carbon film
22k, 5%, 1/8 W,
carbon film
470 Q, 5%, 1/8 W,
carbon film
49.9k, 1%
390k, 5%, 1/8 W,
carbon film
2.1k, 1%
MANUFACTURER €
PART NUMBER
TRW/IRC Special
Spectrol 64X504
Spectrol 64X503
Spectrol 64X253
RN50
RN50
EBERLINE
PART NUMBER
RECC242B21.
RECC120B21
RECC271B21
RECC102B21
RECC271B22
КЕССІ06В22:
КЕХХ22
КЕССІ04В22
КЕСС220В22
РТСЕ504В23
РТСЕ503В33
РТСЕ253В13
RECC473B21
RECC305B21
RECC914B21
RECC203B21
RECC753B21
RECC183B21
RECC204B21
RECC303B21
RECC223B21
RECC471B21
RECE493B11
RECC394B21
RECE212B11
