Core Logic
Mobile Intel® H170 Express Chipset
Display
15.6" (39.62cm) FHD (1920 * 1080) / HD
(1366 * 768), 3.8 mm, 16:9 Backlit Panel
Memory
Dual Channel DDR4
Two 260 Pin SO-DIMM Sockets
Supporting DDR4 2133 MHz Memory
Modules (real operational frequency
depends on the FSB of the processor)
Memory Expandable up to 32GB
(maximum), Compatible with 4GB/8GB/
16GB Modules
Storage
One Changeable 2.5" 7mm(h) Hard Disk
Drives (HDD) / Solid State Drives (SSD)
with SATA Interface
One M.2 2280 SSD with SATA Interface
(Factory Option)
OR
One M.2 2280 SSD with PCIe Gen x3/x4
Interface (Factory Option)
One Changeable Super Multi 9.5 mm (h)
Optical Device Drive (ODD) with SATA
Interface
One Changeable Caddy Bay for 9.5 mm
(h) Optical Device Drive (ODD), 2.5"
7 mm (h) HDD / SSD with SATA Interface
(Factory Option)
Audio
High Definition Audio
S/PDIF Digital Output
Built-In Microphone
Built-In Array Microphone (Factory
Option)
2 Built-In 2W Speakers
Keyboard & Pointing Device
Full Size Keyboard with Numeric Pad
Full Size White LED Illuminated
Keyboard with Numeric Pad (Factory
Option)
Built-In TouchPad (with Multi Gesture &
Scrolling Functionality)
Interface
Two USB 2.0 Ports
Two USB 3.0 (USB 3.1 Gen
1)
Ports
(Type-A)
One USB 3.0 (USB 3.1 Gen
1)
Port
(Type-C)
===============================
*Note: The maximum amount of current supplied
by USB Type-C ports is 500 mA for USB2.0/900
mA for USB 3.1
===============================
One HDMI™ (High-Definition Multimedia
Interface) Out Port (with HDCP)
One External Monitor Port
One S/PDIF Coaxial Out Jack
One Headphone/Speaker-Out Jack
One Microphone-In Jack
One RJ-45 LAN
Jack
One DC-In Jack
One USB 3.1 (Gen 2 - Type A) Port &
One USB 3.1 (Gen 2 - Type C) Port
(Factory Option shared with USB 3.0
ports) - 2 * USB 3.1 Gen 2 Ports with
10Gb Shared Bandwidth
