Removing the Battery
It is possible to remove the battery from the computer, however we recommend that you do not remove the bat-
tery yourself. If you do need to remove the battery for any reason (e.g. long term storage) see below.
1.
Turn the computer off, and turn it over.
2.
Slide the latch
3.
Slide the latch
1 in the direction of the arrow.
2 in the direction of the arrow, and hold it in place.
4.
Slide the battery out in the direction of the arrow 3 .
5.
Reinsert the battery as illustrated below 4 .
6.
Make sure the latches are returned to the lock position 5 .
1
Bottom Cover
Removal
Warning
2
3
Do not remove any
cover(s)
and /or screw(s) for the pur-
poses of device upgrade as
this may violate the terms of
your warranty.
If you need to
replace/re-
4
5
move the hard
disk/RAM/op-
tical device etc., for
any
5
reason, please contact
your
distributor/supplier
for further
information.
Figure 1 - 10 - Battery Removal & Insertion
1 - 18 Removing the Battery
