Page #13 background imageLoading...
Page #13 background image
REMARKSDESCRIPTIONQTYPART NUMBERITEM
COIL, IGNITION1A4110002641
SCREW 5X202900162050202
LEAD, GROUND1V4850006203
LEAD, IGNITION1V4850006804
CLIP1V4900003105
BUSHING1150114049206
SPACER2150117164307
GROMMET1V1350000108
CAP, SPARK PLUG1A4270000129
TERMINAL, SPARK PLUG CAP1A42600001010
SPARK PLUG -- BPM-8Y11590101983011
CANADA MODELSSPARK PLUG -- BPMR-8Y1A42500000012
FLYWHEEL1A40900027213
WOODRUFF KEY11001421233014
FLANGE NUT19005150000815
99922204125 - 13 - REVISED 08/10/07
Table of Contents Part Number Index
CS-400 Chain Saw Ignition, Flywheel

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Echo CS-400 - PARTS CATALOG SERIAL NUMBER C09212001001 - C09212999999 and is the answer not in the manual?

Echo CS-400 - PARTS CATALOG SERIAL NUMBER C09212001001 - C09212999999 Specifications

General IconGeneral
Engine Type2-Stroke
Bar Length16 in
Oil Capacity8.5 oz
Fuel Capacity14.9 oz
Guide Bar Length16 in
Chain Gauge0.050 in
Spark PlugNGK
