Echo CS-400 - PARTS CATALOG SERIAL NUMBER C10013001001 - C10013999999 User Manual

REMARKSDESCRIPTIONQTYPART NUMBERITEM
CARBURETOR -- WT-8201A021001310
SCREW, METERING DIAPHRAGM
COVER
4123130029601
COVER, METERING DIAPHRAGM1123142039302
NOT AVAILABLE SEPARATELYBODY, CARBURETOR------------------3
SHAFT, CHOKE1P0030001504
WASHER1123149260305
LEVER, FAST IDLE1P0030015106
SPRING, CHOKE RETURN1P0030001407
CLIP1123127150308
SCREW, THROTTLE LEVER1123114388309
LEVER, THROTTLE1P00300178010
SCREW, CLIP41231300296011
CLIP, THROTTLE SHAFT11231270393012
SCREW, CHOKE VALVE11231143883013
VALVE, CHOKE1P00300179014
SCREW, THROTTLE VALVE11231143883015
VALVE, THROTTLE11231161053016
SPRING, THROTTLE RETURN11231133753017
SHAFT, THROTTLE1P00300181018
CAP, MIXTURE LIMITER2P00300001019
NEEDLE, MIXTURE ADJUSTMENT21231230633120
SCREW, IDLE ADJUST11231340426021
SPRING, IDLE ADJUST11231330426022
PLUG, FRICTION11231781503023
COVER, FUEL PUMP11231243833024
SCREW, PUMP COVER11231100393025
SCREW, METERING LEVER PIN11231390393026
SPRING, METERING LEVER11231223933027
INCLUDES ITEM 29-37REPAIR KIT1P00300025028
DIAPHRAGM, METERING1------------------29
GASKET, METERING DIAPHRAGM1------------------30
LEVER, METERING1------------------31
PIN, METERING LEVER1------------------32
VALVE, INLET NEEDLE1------------------33
PLUG, WELCH1------------------34
SCREEN, INLET1------------------35
DIAPHRAGM, FUEL PUMP1------------------36
GASKET, FUEL PUMP1------------------37
INCLUDES ITEM 39-42DIAPHRAGM/GASKET KIT1P00300024038
DIAPHRAGM, METERING1------------------39
GASKET, METERING DIAPHRAGM1------------------40
DIAPHRAGM, FUEL PUMP1------------------41
GASKET, FUEL PUMP1------------------42
99922204127 - 7 - REVISED 08/10/07
Table of Contents Part Number Index
CS-400 Chain Saw Carburetor -- WT-820

Echo CS-400 - PARTS CATALOG SERIAL NUMBER C10013001001 - C10013999999 Specifications

General

Ignition System	Electronic
Fuel Tank Capacity	410 ml
Recommended Bar Length	40 cm (16 inches)
Chain Pitch	3/8 inch
Chain Gauge	0.050 in
Starter System	Recoil
