OPERATION CS-4920
32 X7503352100
© 09/2022 ECHO Incorporated
4. Pull choke control knob (A) all
the way OUT (CLOSED [ ]
choke position).
5. Push purge bulb (B) 3 to 4
times or until fuel is visible in
purge bulb.
6. Securely hold the chainsaw as
shown and pull starter handle
several times until first starting
sound.
7. Push choke control knob (A) all
the way IN (OPEN [ ]choke
position).
8. Pull starter handle to start the
engine.
9. When engine starts,
immediately squeeze and
release throttle trigger (C) to
release fast idle throttle latch
otherwise severe brake
damage may occur.
Note: Do not pull starter rope
out to the maximum
possible position. Do not
allow recoil handle to
snap back against the case. If engine does not start after 5
pulls, repeat instructions. Do not increase engine speed while
chain brake is locked. Severe brake damage will result.
