Echogear EGCM1 - Page 9

11
Mark
2.3
Drill
2.4
1/8 in.
(3 mm)
3 in. (7.5 cm)
Bit
Secure Wall Plate
2.5
CAUTION: Avoid potential personal injury
or property damage! Lag screws
7
MUST
BE firmly tightened to prevent unwanted
movement of the wall plate/arm
6
.
7
8
5
6
